6-1
Chapter 6.
Editing Standard Component Properties
Introduction 4007ES panels come equipped with a standard set of hardware components. This chapter
details the programming for those cards.
In this chapter
Accessing
Properties
1. Open the Hardware tab.
2. Select the hardware component from the Hardware Configuration window and double-click
on it to open the editing window.
Editing the Unit
Properties
Each 4007ES panel set-up automatically requires a unit in the programmer.
To edit the unit:
The Unit Window requests that the user enters the following information:
• Description: Enter a description that identifies the particular FACP.
• AC Breaker Location: Enter the location of the breaker that powers the unit’s power
supply.
Editing the CPU The 4007 CPU window has three main tabs to edit. The Card Properties tab, the Service Port
tab, and the Ethernet tab.
To edit the Card Properties tab (Figure 6-1):
Enter the card’s custom label. This label should make the card easily identifiable.
The following fields in the tab are filled by the programmer and cannot be edited:
• Card address
• Card description
• Card default label
• Annunciator address
• Unit number
• Box number
• Bay number
• Location
To edit the Service Port tab (used as an output for ExacTech and TrueInsight):
1. Configure the communication settings by selecting the Baud Rate, Parity, Data Bits, and
Stop Bits fields to the values required by the attached device. It is recommended that you
use the following default settings whenever possible.
• Baud Rate: 115,200
• Data Bits: 8
• Stop Bits: 1
• Parity: None
2. Click on the Port Data button. The RS323 Port Data Entry window opens (Figure 6-1).
Continued on next page
Accessing Properties............................. 6-1 Editing the IDNET Multiloop........ 6-7
Editing the Unit Properties ................... 6-1 Editing the NAC Power Supply..... 6-9
Editing the CPU .................................... 6-1 Editing the Zone/Relay Card ....... 6-11
Editing the Color User Interface........... 6-3
Editing the Serial DACT Card Per Point
..................................................... 6-13
Editing the IDNAC Power Supply........ 6-5 Editing the Event DACT Card..... 6-15
48-LED Module..................................6-17
