Chapter 2.
User Interface
Introduction The user interface has menus, icons, tabs, sub-tabs, and a status bar that help the user navigate
through the programmer and create jobs.
The following sections detail the user interface and the options associated with each item.
Figure 2-1. 4007ES Programmer Interface
In this chapter
Menus The menus are located at the top of the ES Panel Programmer:
Consult the following tables for the description of the menu items.
Icons
Tabs
Sub-Tabs
Status Bar
Menus
Toolbar
Menus ..............................................2-1 Toolbar Icons ...................................2-4
Tabs and Sub-Tabs...........................2-5 Status bar..........................................2-5
Table 2-1. File Menu
Menu Item Description Menu Item Description
New Creates a new job. Archive Archives the job.
Open Opens an existing job. Backup Backs up the job.
Close Closes the current job. Restore Restores the previous saved version of
the job.
Save Saves the current job. Export Allows the user to:
• Export data to service sales tools
• Export user points to text file
• Export XLG point data
Save as Allows you to copy or rename the
current job.
Reports Generates a digital job report. Import Allow the importation of user points
from another file.
View report Brings up the latest report. DB Compare Compares the job to previous revisions
of itself.
Print set up Configures the hard copy print
specifications.
Current Job The name of the current job.
Print Label Prints labels for the FACP cards. Exit Exits the current job.
