Simplex 4007ES Programmer's Manual

9-9
4007ES Panel Programmer Manual (579-1167)
Custom Control, Continued
Selecting Floor
Tab
1. Start the Floor Above/Below Wizard by clicking on the Floor Above/Floor Below Wizard
tab, which is located along the bottom left part of the Custom Control window.
2. Right click in the blank area above the tab. When the list of options appears, select Create
Floor Group. (The ES Panel refers to each set of floor above/below equations as a Floor
Group. This is the name of the group or area that the floor above/below program has control
over.) Enter a name for the Floor Group in the dialog that appears.
.
Figure 9-13. Create Floor Group
.
Figure 9-14. Select Group

Simplex 4007ES Specifications

General

Model	4007ES
Category	Fire Alarms
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Display	4.3-inch color touchscreen
Power Supply	120/240 VAC, 50/60 Hz
Network Connectivity	Ethernet, RS-232, RS-485
Addressable Points	250
Communication Protocols	MAPNET II
Notification Appliance Circuits	4 NACs
Total Points	250
Annunciation	Yes
Max Devices	250
Max Notification Circuits	4
Communication Ports	RS-232, USB
