Page #24 background imageLoading...
Page #24 background image
4-2
4007ES Panel Programmer Manual (579-1167)
Panel Information • Programmed by: This section requests information about the people who programmed
the FACP (branch, customer information).
• Hardware Edit Lock: When this option is checked, the user cannot add or remove any
hardware.
• Comment: Enter any comments about this specific FACP.
System Options ES Panel System Options are global attributes that allow the user to configure specific
application options as well as configure certain elements of the panel's display.
To access the System Options screen:
1. Click on the Panel tab and select the System Options sub-tab.
2. Configure the options that appear on the page. The following tables list and define the
different options.
Table 4-2. General System Options
Option
Description
(“dflt” indicates the default setting)
Date Format
• Select MM-DD-YY
dflt
for the panel to display the date by month, day, and
year (example: January 4th 2013 = 01-04-13).
• Select DD-MM-YY for the panel to display the date by day, month, and year
(example: January 4th 2013 = 04-01-13).
Time Format
• Select 12 Hour
dflt
for the panel to display the time as “a.m.” and “p.m.”
(example: 6:00 a.m., 6:00 p.m.)
• Select 24 Hour for the panel to display the time on a 24h clock (example:
6h00, 18h00.)
Unit Format
• Select Fahrenheit
dflt
for the panel to display Imperial units.
(example: 96
o
F, 6 ft)
• Select Centigrade for the panel to display Metric units.
(example: 36
o
C, 1.83 m)
Acknowledge
Option
• Select Global acknowledge
dfl
to allow every point reporting the same alarm
state (alarm, trouble, priority 2, or supervisory condition) to be
acknowledged at once by pressing the according Acknowledge button.
(Example: If 5 Trouble conditions are present on the system and global
acknowledge is enabled, one press of the Trouble Ack button
acknowledges all five Troubles at the same time.)
• Select Individual Acknowledge to ensure that each point reporting an
alarm state must be acknowledged individually. (example: If five Trouble
conditions are present, acknowledge each one individually.)
Standard Select the system listing standard. The options are:
• None
dfl
• UL (US)
• ULC (Canada)
Panel Information and Configuration, Continued
Continued on next page
