¾
To select the data source for a channel where more than
one option is available:
• Select Pages then Setup from the main menu.
• Select + Data Sources to display a list of options.
• When you are finished, select
Return.
2.5 Setup: Tracks
¾
To enter setup options for Tracks
• Select Pages then Setup from the main menu.
• Select
+ Tracks to display a list of options.
• When you are finished, select
Return.
-Tracks Default Description
Record Vessel Tracks
On / Off
On
Enables the system to record the
vessel's track history.
Cross track distance to create track point
0-3000 ft
33
Sets the cross track threshold before
a track point is laid.
Distance to create track point
0.01-10 N
0.1
Sets the interval between track points
along a straight course.
Max track points shown
1,000-
10,000
2000
Sets the maximum amount of track
points used. After the maximum is
reached track points from the
beginning are deleted.
20 | Setup
