¾
To change the depth line setting:
• Display the Echosounder pane and the main menu. If you can't
see the
Display Options button, select Return.
• The
Depth Line button shows the current setting. Select it to
change the setting.
Note: If you can't see the depth line, check whether it's On. If
it
is On but you can't see it, try changing the range because it
may be out of view.
¾
To move the depth line:
• Display the Echosounder pane and the main menu. If you can't
see the
Move Depth Line button, select Display
Options.
• Select
Move Depth Line, then move the depth line.
• Select
OK.
7.13 Echosounder: Depth value
You can show or hide the depth value on your Echosounder pane
only. If you choose to show the depth value, you can select a small
or large pane.
Large is the default.
¾
To show or hide the depth value:
• Display the Echosounder pane and the main menu.
• The
Depth Value button shows the current setting. Select it
to change the setting.
7.14 Echosounder: 50/200 kHz split screen
You can show the 50 kHz history in one pane and the 200 kHz
history in the other.
This can be useful if you're operating in shallow to medium water,
typically less than 500 ft (150 m), and want to compare a wide
view of the local area (50 kHz) with a more detailed view of the
area under your vessel (200 kHz).
Note: You can't use any of the zoom features on this pane.
98 | Echosounder
