Operation
20169223D 2-11
COMP. DIFF. 5°
PRESS INC.
IIIIIIIIIIIIIII
NAV. FILTER 1.1
IIIIIIIIIIIIIII
NAV. GAIN 1.0
IIIIIIIIIIIIIII
NAV. TRIM 180s
Press
INFO
INFO
INFO
Press
Press
Only if NAV is selected
and CTS is NOT selected
Range: 1.1 - 2.5
Recommended: 1.1
Range: OFF - 3,2
Recommended: 1.0
Range: 100s - 1600s
Recommended: 180s
Press INC to zero-set the relative
difference between the two
compasses. The actual difference is
then shown in the display.
INFO
Press
Next press repeats the INFO loop 1
INFO loop 2
(For detailed description, see Sea Trial, page 5-62)
To enter this loop, do as follows:
• Press the INFO button and keep it pressed
• Press and release WEATHER button
• Release the INFO button
The display will now show:
* * * * * * *
ENGLISH
This is the language parameter. Use INCREASE/DECREASE to select
the required language. The different options are:
ENGLISH – FRANCAIS – ESPANOL – NORSK
