Appendix C - Pinouts
130
Matrix
2
Owner’s Manual
X-Rack / Diag
Location: Matrix rear panel
Connector Type: 9-way D-type female
Pin Description Notes
1
6
2
7
3
8
4
9
5
Matrix 25-way D pinouts
Location: Matrix rear panel
Connector Type: 25-way D-type female
Circuit hot cold screen
Rec, Mix, Cue Send Rec, Mix, Cue Rtn Cue St, FX1-4 Snd FX1-4 Rtn
1 24 12 25 Rec Send L Rec Return L Cue Out L FX return 1L
2 10 23 11 Rec Send R Rec Return R Cue Out R FX return 1R
3 21 9 22 Mix Send L Mix Return L FX 1 Out FX return 2L
4 7 20 8 Mix Send R Mix Return R FX 2 Out FX return 2R
5 18 6 19 Cue Send L Cue Return L FX 3 Out FX return 3L
6 4 17 5 Cue Send R Cue Return R FX 4 Out FX return 3R
7 15 3 16 - - - FX return 4L
8 1 14 2 - - - FX return 4R
Surround Monitor Card 25-way D pinouts
Location: Matrix rear panel
Connector Type: 25-way D-type female
Circuit hot cold screen
EXT 1,2 MON, MINI
1 24 12 25 EXT 1 C MON out C
2 10 23 11 EXT 1 LFE MON out LFE
3 21 9 22 EXT 1 LS MON out LS
4 7 20 8 EXT 1 RS MON out RS
5 18 6 19 EXT 2 C MINI out C
6 4 17 5 EXT 2 LFE MINI out LFE
7 15 3 16 EXT 2 LS MINI out LS
8 1 14 2 EXT 2 RS MINI out RS
Matrix 25-way D pinouts
Location: Matrix rear panel
Connector Type: 25-way D-type female
Circuit hot cold screen
Channels 1-8, 9-16 Ext 1, 2 Mon LS Artist out Rec, Mix F/Mon
1 24 12 25 Channel 1 (9) Ext 1 Input L Mon Out L Rec Out L
2 10 23 11 Channel 2 (10) Ext 1 Input R Mon Out R Rec Out R
3 21 9 22 Channel 3 (11) Ext 2 Input L Mini Out L Mix Out L
4 7 20 8 Channel 4 (12) Ext 2 Input R Mini Out R Mix Out R
5 18 6 19 Channel 5 (13) - Artist Out L Follow Mon Out L
6 4 17 5 Channel 6 (14) - Artist Out R Follow Mon Out R
7 15 3 16 Channel 7 (15) - - -
8 1 14 2 Channel 8 (16) - - -
