Mon So Keys
The Mon menu allows you to cut or solo individual monitor outputs in your 5.1 setup. By default, pressing any of the Left,
Centre, Right, LSurr, RSurr, Sub
buttons will cut the relevant output. Pressing the Solo
the buttons from Cut to Solo mode. The
Mtr5.1 button switches between 5.1 and stereo monitor outputs. The Mtr5.1 button
also changes the MIX, REC and MON meters on the meterbridge from 3 stereo meters to a single 5.1 meter.
Meters So Keys
The Meters
eight lower buttons in the soft key area are in three groups: buttons 1 and 2 prevent the meters from following the console’s
Focus mode by locking them to either the analogue or DAW signals, buttons 3 and 4 provide peak hold options, and buttons 5
to 8 provide meter source options for analogue metering. All buttons cancel out other selections made within that group, and
can be returned to their default state by pressing the currently selected option:
for details
Focus Options
By default, the meters follow the console’s Focus mode, displaying the analogue channel levels in Analogue Focus mode, and the
levels in the DAW tracks in DAW Focus mode. Pressing
Analog causes the meters to stay with the analogue channel levels, and
pressing
DAW causes the meters to stay with the DAW track levels, regardless of the console’s Focus mode.
Peak Hold Options:
Peak Hold is where the top segment lit by any momentary peak levels remains lit once the level drops. By default, the meters do
not have a peak hold. Pressing
Peak introduces a 3 second peak hold, and pressing Hold
can be reset by cancelling the
Hold button.
Meter Source Options:
There are four source options for the channel meters: CHIP (channel input post-gain), CHOP (channel output), DAW Return
(DAW return pre-gain), and
Post (post fader).
Chapter 3 - Analogue Signal Flow
46
Matrix
2
Owner’s Manual
