Inserting Preset Chains
Any CHAINS of devices you have previously saved can be inserted using the CHAINS button (see “Chapter 4 - Matrix Remote”
for creating preset chains).
To insert a preset
CHAINCHAIN button. The LCD on the right-hand side of Matrix will now
change to show the names of any Preset Chains you have stored on the top row, with additional
<< and >> keys.
The button directly above the name Preset Chain will light yellow if available or will be unlit if already in use.
Like with Devices, use the upper
SEL key to selected the desired channel and then press the button directly above the desired
Chain name. The bottom row of the main scribble strip will now display the name of the Chain below the channel name.
At the same time, the bottom row of the right-hand LCD scribble strip will display which devices you have in that particular chain
(providing that channel is still selected).
Removing Assigned Devices
When in either DEVICES or CHAINS mode, if a device/chain you want to use is already in use, the button does not light. You
can see which channel it is already in use on by simply pressing it. The device label will change to display the channel number e.g.
“Chan 10” and the
MODE display will change to indicate the slot it is currently inserted on.
To remove the device simply press and hold the desired device button until it re-lights yellow. It is now available to insert using
the normal method.
Chapter 3 - Analogue Signal Flow
43
Matrix
2
Owner’s Manual
