Editing Transport and Utility Button Assignments
In addition to the main 16 soft keys, the function of 18 other buttons and the two foot switch inputs can be edited, increasing
the total number of assignable soft keys within the four layers to 380. This is likely to be useful if you are using DAW packages
be that the way you work means that there are some controls which you never use and other functions which would be more
usefully accessed from those buttons.
The 18 buttons which are editable in this way are:
- The ten buttons above the main transport controls, the top left of which is labelled
PREVIOUS,
- The six right-most utility buttons located above them, the top left of which is labelled
SHIFT,
- The
SAVE and UNDO buttons located above and to the right of the main soft key area.
and
To edit these button assignments, press the
Transport/Utility radio button at the right-hand end of the Soft Key Set row
in the
DAW tab, bringing up a representational display of these buttons:
The buttons in the tab are distinguished by the Matrix console labels above each button. The current button assignments are
indicated below each button. If the button is currently unassigned, the label below the button will consist of six dashes.
These buttons are assigned in exactly the same way as the normal soft keys.
Chapter 6 - DAW and CC Conguration
115
Matrix
2
Owner’s Manual
