Appendix B - Technical Specications
Performance Figures
Headroom < +26dBu @ 1kHz (< 1% THD)
Line In to Direct Out
Frequency Response ±0dB at 20Hz, +0/-0.1dB at 20kHz, -1dB at 80kHz
Noise < -89dBu 20Hz - 22kHz
Line to Aux Bus Out
Frequency Response ±0dB at 20Hz, +0/-0.1dB at 20kHz
Noise < -93dBu (no channels routed)
< -76dBu (all channels routed, faders at 0dB)
Line To Mix/Rec Bus Out
Frequency Response ±0dB at 20Hz, +0/-0.1dB at 20kHz
Noise < -89dBu (no channels routed)
< -77.5dBu (all channels routed, faders at 0dB, pan at centre)
Matrix Power Supply
Parameter Value Unit Notes
Width 106 mm
Height 202 mm
Depth 306 mm
Weight 5 kg
Heat Dissipation 45 W
Noise - - fanless
Voltage 100 - 240 V
Current 2.0 - 1.0 A
Connector (mains input) IEC320 10A Male
Matrix Console
Parameter Value Unit Notes
Width 946 mm
Height 228 mm
Depth 724 mm
Weight 25 kg
Heat Dissipation 130 W
Noise - - fanless
Connector (DC power input) BICC 12-pin Male
Appendix B - Technical Specications
125
