Matrix Digital IO Specications
signal level is -1dB FS.
Stereo ADC
Source selectable between Mix bus, Record bus and Monitor (pre level control) signals.
Connections: S/PDIF (TosLink optical) and AES-3 (male XLR). Signal available on both connectors at all times.
Sample rate - locks to selected digital input up to a maximum sample rate of 192kHz. In the absence of a valid digital input
defaults to 48kHz.
Dynamic range typically 113dB A-weighted, 111dB unweighted. Worst case 108dB unweighted
THD < 0.0015%
0dB FS switchable between +18dBu and +24dBu
DAC
Connections: source selectable from Matrix front panel between S/PDIF (TosLink optical) and AES-3 (female XLR) inputs.
Sample rate 32kHz to 192kHz
Dynamic range typically 116dB A-weighted, 111dB unweighted. Worst case 109dB unweighted
THD < 0.001%
0dBFs switchable between +18dBu and +24dBu
Appendix B - Technical Specications
126
