6 - 41HJYLC3 Channel LCD Replacement
• Follow instruction #4 for 629502XA removal to reveal the display.
• Remove the three pan Pozi screws and remove the assembly.
• Fit new assembly and screw in place.
• Reassemble and test for correct operation.
7 - 41HJYLC3 Centre Section LCD Replacement
• Follow instruction #4 for 629506XA removal to reveal the display.
• Remove the three pan Pozi screws and remove the assembly.
• Fit new assembly and screw in place.
• Reassemble and test for correct operation.
