Master Input Flip
This button works in any desk status and simply flips all channel inputs between Mic
and Line inputs. Each channel can be flipped on an individual basis but it is simpler to
hit MASTER INPUT FLIP to select the majority type of input. You would use this
button if, for example, you are working in the RECORD status and wish to use Line
inputs for synthesisers or samplers, rather than the Mic inputs.
Replay Status
This mode is used when working in RECORD, or RECORD + SMALL FADER TO
MON status. The current console status is put on ‘standby’ and the tape returns are
automatically routed to the Monitor faders. This allows a quick replay of the tape
without disrupting the console setup. If the Sync/Replay option is wired, then an
analogue multitrack machine will be switched to normal Replay.
This status is useful during track laying. For example, when operating in RECORD
status, the time will come when a quick monitor mix is required. This can be
accomplished in RECORD status by deselecting any GROUP buttons, switching the
multitrack machine to Replay manually, and mixing down the monitor inputs via the
main output busses onto a stereo ATR. REPLAY status does all this with one button.
Any GROUP selections are temporarily disabled and the monitor inputs pick up
multitrack returns from the Replay head.
Reselecting RECORD status will reinstate all the previous GROUP and TAPE button
selections, and an analogue multitrack will switch back to Sync, ready for more
recording.
REPLAY status is also useful for playback over the Studio Loudspeakers, as RECORD
status prevents the SLS outputs from receiving signal.
Basic Routing and Signal Flow
2-13
5.9.96
