Small Fader Source and Destination
The console STATUS buttons determine if the Small Fader is placed in the Monitor or
Channel signal path. (See Section 2 for more details.)
The Small Fader can be routed direct to the main stereo Mix bus by selecting the SF
MIX button.
For your reference, the sources and destinations of the Small Fader signal are shown
below. The destinations shown are the default selections; these can be over-ridden
locally at any time:
Group/Tape Selections and the Supercue System
The GROUP and TAPE buttons are used to select monitor sources for the Monitor
fader and to determine the Pre-Fader Cue feeds. As already described, these buttons
also enable the module track RECORD facility. The table below lists the different
combinations of buttons and the resultant signals that are fed to the Monitor fader and
the Aux sends:
The SL911 Input/Output Module
3-13
15.9.94
Status Buttons Selected Small Fader Input Small Fader Output
MIX Monitor Input Routing Matrix
RECORD Channel Input Routing Matrix
RECORD + Monitor Input Stereo Mix Bus
SMALL FADER TO MON
Ready Button Monitor Fader Pre-Fader Record Switch
Selected Source Aux Feeds Enabled?
None TAPE TAPE NO
TAPE TAPE TAPE YES
GROUP GROUP GROUP YES
GROUP+TAPE GROUP+TAPE GROUP+TAPE YES
