The preset may be named by stabbing in the Name box and entering up to eight
characters via the QWERTY pop-up or dedicated keyboard. To define or alter the serial
number/name of the PatchBay to which the preset relates, stab on the PatchBay S/N
box and select the required PatchBay via the pop-up. (This pop-up is the same as the
one used to select different PatchBay crosspoint displays.)
The three boxes designated 1-8, 9-16 and 17-24 enable ‘block’ assignment to be quickly
set up. Simply stab on the box which will make the required connections (these
selections toggle). For more specific assignments, stab on a box in the Column row
and enter an appropriate Input/Output number (1-24) on the numeric pop-up. Clear
may be used to clear any erroneous or existing assignments. OK out of the preset pop-
up.
An alternative method is provided so that the assignments for each preset may be set
up on the crosspoint display itself. It is advisable to check that the preset you intend to
use is clear of any assignments before you carry out this procedure, as previous
assignments will be ignored when entering new assignments by this method.
Select Make Block. Now stab on the crosspoint display to make up to eight
assignments. To enter these into the required preset, stab on a ‘Block’ box. Stab on the
‘Block’ box again to check that the preset applies to the correct PatchBay, and enter a
name if desired.
The action of any preset may be tested here by stabbing on the yellow box to the left of
the ‘Block’ box, to toggle the preset on/off. You must of course have the relevant
PatchBay display currently selected in order to see the result.
Machines Menu
7-13
16.8.96
