SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
Key
Description of the Usage
ZOOM
zoom ultrasound image.
DIST
measure the distance between two points.
TRACE
press this key and move the trackball to draw a trace on the
ultrasound image; press SET to close the trace.
ELLIPSE
press this key and move the trackball to draw an ellipse on the
ultrasound image.
CALC
press this key to activate the measurement menu.
TGC
slide the TGC control to change the gain in the corresponding
2D depth.
P/N: 4701-0061-01B
2-11
