SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
Load new setting?
continue (Y/N).
Delete setting: [DEL]
Type Y to load the setting or type N to cancel. Press DELETE to delete the setting.
To save the current system setting as a new setting, click the Create tab. Type in
the name for the setting, and click CONFIRM.
Figure 4.14: Create a user setting
To back up or retrieve the user setting and data, click the Retrieve tab.
• Click Copy user setting to USB to back up the current user setting and patient data
to an external USB drive. Make sure to connect the USB drive before performing
the backup.
• Click Copy USB user setting to system to copy the backup (setting and data) from
the USB drive.
Figure 4.15: Back up or load the user setting and data
Warning!
Copy backup from the USB drive overwrites the patient data
on the system as well.
P/N: 4701-0061-01B
4-10
