The STM32 Cortex-M0 processor PM0215
14/91 Doc ID 022979 Rev 1
Application program status register
Contains the current state of The condition flags from previous instruction executions. See
the register summary in Table 3 on page 12 for its attributes.
Interrupt program status register
Contains the exception type number of the current Interrupt Service Routine (ISR). See the
register summary in Table 3 on page 12 for its attributes.
Table 5. APSR bit definitions
Bits Description
Bit 31 N: Negative or less than flag:
0: Operation result was positive, zero, greater than, or equal
1: Operation result was negative or less than.
Bit 30 Z: Zero flag:
0: Operation result was not zero
1: Operation result was zero.
Bit 29 C: Carry or borrow flag:
0: Add operation did not result in a carry bit or subtract operation resulted in a
borrow bit
1: Add operation resulted in a carry bit or subtract operation did not result in a
borrow bit.
Bit 28 V: Overflow flag:
0: Operation did not result in an overflow
1: Operation resulted in an overflow.
Bits 27:0 Reserved.
Table 6. IPSR bit definitions
Bits Description
Bits 31:6 Reserved
Bits 5:0 ISR_NUMBER: This is the number of the current exception, see Exception types on
page 22 for more information:
0: Thread mode
1: Resetrved
2: NMI
3: Hard fault
4-10: Reserved
11: SVCall
12: Reserved
13: Reserved
14: PendSV
15: SysTick/Reserved
16: IRQ0
....
47: IRQ31 (see STM32 product reference manual/datasheet for interrupt mapping
information)
48-63: Reserved
