The STM32 Cortex-M0 instruction set PM0215

60/91 Doc ID 022979 Rev 1

Restrictions

The restrictions are:

● Do not use SP or PC in the BX or BLX instruction

● For BX and BLX, bit[0] of Rm must be 1 for correct execution. Bit[0] is used to update

the EPSR T-bit and is discarded from the target address.

Bcond is the only conditional instruction on the Cortex-M0 processor.

Condition flags

These instructions do not change the flags.

Examples

B loopA ; Branch to loopA

BL funC ; Branch with link (Call) to function funC, return address

; stored in LR

BX LR ; Return from function call

BLX R0 ; Branch with link and exchange (Call) to a address stored

; in R0

BEQ labelD ; Conditionally branch to labelD if last flag setting

; instruction set the Z flag, else do not branch.

BL label −16 MB to +16 MB

BX Rm Any value in register

BLX Rm Any value in register

Table 22. Branch ranges (continued)

Instruction Branch range
