4-13
Operating Instructions Operator Manual 056404-443
4.14 Accessories/Side Rails
The standard STERIS permanently attached 3/8" wide x 1-1/8" tall (9.5 x 28.6 mm) side rails allow for the use of
many standard surgery table attachments and accessories. The rails consist of one rail mounted to each side of
each tabletop main section.
IMPORTANT: Regarding Side Rail Loading —
• Side Rail loading (with exception of Dual-Articulating Headrest rails) has been evaluated through cantilevered
testing to support 200 ft-lb (271 N•m) maximum. Any additional loading needs to consider table stability.
• Dual-articulating headrest side rails support 100 ft-lbs. (135 N•m) maximum. The headrest end rail supports
50 ft-lbs. (67 N•m) maximum.
For complete information on accessory options, consult STERIS.
* Contact STERIS for ordering information.
WARNING – PERSONAL INJURY HAZARD:
When installing any table accessory, check for correct attachment and tighten securely (if
appropriate). Do not use a worn or damaged accessory. Before using any accessory, ensure it has
been installed properly.
WARNING – INSTABILITY HAZARD:
Possible patient or user injury, as well as table or accessory failure, may result from using STERIS
table accessories for other than their stated purpose – or from using accessories manufactured
and sold by other companies on STERIS surgical tables.
Table 4-1. STERIS 4095 General Surgical Table Specific Accessories*
Accessory Equipment Number
FootContrrol BF586
HandControl BF319
TLTTablePads(CompleteSet)–Hook-and-Loop BF58(2”)•BF230(3”)•BF291(4”)
PRSTablePads(CompleteSet)–Mushroom-Type BF272(2”)•BF279(3”)•BF245(4”)
X-RayTop(CompleteSet)–Hook-and-Loop BF101
X-RayTop(CompleteSet)–MushroomType BF193
