01 ENGINE
Page ENGINE - 52 Z001019/0_6_July 2008
SERVICE MANUAL MARINE ENGINES
01.05.02 Replace valve stem gasket
(on engine assembly)
Preparation: Disassemble camshaft housing,
01.05.01.
ATTENTION:Set piston of respective cylinder on
TDC.
1 Mount valve spring retainer No. VR00105/1 (ill.1).
2 Presstress valve spring (ill.2) with hexagon socket
(SW28).
3 Remove wedges.
4 Relax valve spring again, remove valve spring and
spring washer.
5 Remove valve stem gasket with special tool No.
2300758/0.
05.02 ill.1
05.02 ill.2
05.02 ill.3
05.02 ill.4
