ELECTRICAL SYSTEM
Page ELECTRICAL SYSTEM - 76 Z001019/0_6_July 2008
SERVICE MANUAL MARINE ENGINES
06.08.03 DC - DC converter
DC-DC Converter
IVO 8770
C
IRCUIT DIAGRAM
Batt "A"
Batt "B"
24VDC
12VDC
U2
16A 25A
Batt "C"
Engine
GU1
I
E
I
A
ToC
