ELECTRICAL SYSTEM
Page ELECTRICAL SYSTEM - 78 Z001019/0_6_July 2008
SERVICE MANUAL MARINE ENGINES
06.10 SENDER AND SENSOR OVERVIEW
06.10.01 Component configuration 4 cyl. engine
PED
J1
DIAG
FMS
MAP
CODE
CODE
BESCHREIBUNG
DESCRIPTION
BESCHREIBUNG
DESCRIPTION
KURZNAME
ABBREVIATION
KURZNAME
ABBREVIATION
RPOS
RPM
ECT
EXT
LPS
Verbindungsstecker Motor - EMS
Connector engine cable - EMS
Diagnose - Stecker
Diagnosis - plug
Steuermagnet
Control solenoid
Stecker Getriebeschalter (Option)
Connector gear switch (optional)
Inversionsschalter (Nur bei SOLAS)
Inversion switch (only for SOLAS)
Abschaltventil (Nur bei SOLAS)
Blow - by (only for SOLAS)
Stecker Ölmanometer (Option)
Connector oil pressure gauge (optional)
Stecker Trimmanzeige (Option)
Connector trim (optional)
Ladedrucksensor
Boost-pressure sensor
Gaspedal
Potentiometer accelerator
Regelstangensensor
Rack position sensor
Motordrehzahlsensor
Sensor engine speed
Kühlflüssigkeitstemperatursensor
Sensor engine coolant temperature
Abgastemperatursensor
Sensor exhaust gas temperature
Öldrucksensor
Lubricant
p
ressure sensor
10.01 ill.1
ECT
94/114/144
164/174
EXT
to engine number 48226999
