06 ELECTRICAL SYSTEM
Page ELECTRICAL SYSTEM - 48 Z001019/0_6_July 2008
SERVICE MANUAL MARINE ENGINES
06. 07. 02 Chart - Error indication on Instrument Panel
Operating condition: During normale engine operation, or indication in case of sensor defect while
ignition is switched ON.
Event: Speed resp. performance limitation during engine operation
80° - 90°C
ON
OFF
ON
OFF
Fault
oil pressure below min.
limit
Remarks
check oil level
Indication status
80° - 90°C
OFF
OFF
OFF
FLASHING
(1x per sec.)
fault oil pressure
sensor or
sensor connection
check oil pressure sensor
(B18) and connection
reduce throttle position
until light goes OFF
(indication during first 2
hours of operation)
ON
engine overload during
break-in period
07.02 ill.2
07.02 ill.3
NOTE: (see cap. general, D3)
A
C
D
E
B 07.02 ill.1
A temperature gauge - coolant D combined light preheating control &
B audible warner warning light engine oil pressure
C warning light - battery charge E warning light check engine
ON
