01 ENGINE
Page ENGINE - 54 Z001019/0_6_July 2008
SERVICE MANUAL MARINE ENGINES
01.05.03 Replace control rack
Preparation: Drain fuel system, 03.02.02
item 2.
Disassemble camshaft housing cover,
01.05.01.
Disassemble control solenoid,
03.08.01.
Disassemble unit injector of
1
st
cylinder, 03.02.02.
1 Disassemble handle to control solenoid by loosening
two hexagon screws (SW8) (ill.2/pos.1).
2 Disassemble all control links (ill.3/pos.1) by
loosening hexagon socket (SW4) (ill.3/pos.2).
ATTENTION: LEFTHAND THREAD
3 Remove setpin (ill.4/pos.1) from last bulkhead.
05.03 ill.2
05.03 ill.3
05.03 ill.4
1
2
1
05.03 ill.1
1
