03.02.05 Loosenxingofcontrolrod
1 Unscrew setpin (ill.3/pos.2) from bulkhead wall with
removing setpin and hold control rack. Reinstall setpin
in rear camshaft housing bore.(ill.3/pos.1).
2 Tighten setpin with a torque of 7 Nm.
3 Checkaxialexibilityofcontrolrack.Controlrackis
to be moved easily and should automatically return
to reverse position due to spring load.
02.05 ill.2
02.05 ill.1
02.05 ill.3
12
