Z001019/0_6_July 2008 Page ENGINE - 85
01 ENGINE
SERVICE MANUAL MARINE ENGINES
01.13.03 Change motor oil
1 Bring engine to operating temperature and stop
engine.
2 Remove oil dipstick (ill.1/pos.1).
3 Open oil filler cap (ill.2/pos.1), but do not remove
because of possible contamination.
4 Suck off motor oil on oil dipstick tube by means of
suction pump No. 0172473/0 (ill.2/pos.2), and pump
it into a suitable receptacle.
NOTE: Pay attention to heat- (approx. 120°C)
and oil resistance of receptacle for the
used motor oil.
Dispose the oil properly.
5 Remove oil filler cap (ill.2/pos.1).
6 Fill in STEYR turbo diesel engine oil SAE 10W-40
(No. Z010058/0) (ill.3) or equivalent motor oil with
characteristics ACEA B4 - 02 or API code CF.
ATTENTION:Oil filling must not exceed the
maximum marker. Overfilling results
in high operating temperatures,
foaming (air in oil), loss in efficiency
and a reduced engine life.
As the quantity for an oil change, refer to
Specifications Motor Oil GENERAL B 2
As the quantity for first filling (e.g. after engine
repair), refer to Specifications Motor Oil GENERAL
B 2
7 Put on oil filler cap and lock.
ATTENTION:Remove possible oil contaminations
from oil filler cap and environment.
ATTENTION:Do not forget oil check after test run.
13.03 ill.1
1
2
1
13.03 ill.2
13.03 ill.3
