Z001019/0_6_July 2008 Page ENGINE - 57
01 ENGINE
SERVICE MANUAL MARINE ENGINES
05.04 ill.5
5 Push out camshaft (ill.5) with radial shaft seal to the
front.
6 Pull out camshaft from the front of camshaft housing.
ATTENTION: On all 4 cyl. and 6 cyl. engines before:
68224400
At the rear end of camshaft (ill.1/pos.2)
the speed sensor wheel is located.
When pulling out and pushing in the
camshaft, take care that bearings of
camshaft are not damaged.
