Z001019/0_8_Octobre 2011 Page GENERAL-9
GENERAL
SERVICE MANUAL MARINE ENGINES
ToC
03.02 ill.4
03.02 ill.5
03.02 ill.6
03.02 ill.7
03.02 ill.8
Transmission
Lifeboat Engine
Equipment
Bobtail "B"
Direkt gearbox
A-down angle gear box
Parallel offset gearbox
i = 2.5V, shaft angle 12°
i = 2.0V, shaft angle 12°
