STEYR 4 CYLINDER User Manual

Z001019/0_6_July 2008 Page COOLING SYSTEM - 29
SERVICE MANUAL MARINE ENGINES
05 COOLING SYSTEM
ASSEMBLY:
1 Clean sealing surfaces on thermostat housing and
on sealing surface of cover.
2 Put seal (ill.6/pos.1) onto thermostat.
4 Insert thermostat into housing, ventilation mark (ill.7/
pos.1) showing upwards.
ATTENTION: Put on new seal.
5 Insert spacer.
6 Remaing assembly is done in reverse order.
7 Tighten screws of thermostat housing cover with a
torque of 10 Nm +/-1.
8 Filling of closed cooling circuit,
refer to 05.00.08
03.02 ill.7
.
03.02 ill.5
03.02 ill.6
1
1
03.02 ill.8
