01 ENGINE
Z001019/0_6_July 2008 Page ENGINE - 25
SERVICE MANUAL MARINE ENGINES
NOTE: If the index value of engine timing
should not correspond to the allowed
value, follow the instructions as per
item 24.
32 In case of correct index value of engine timing,
tighten hexagon nut of camshaft sprocket (SW 30)
with 240 Nm +/-12 by holding up with special tool No.
2300711/0.
33 ATTENTION: The following torques are to be
checked again:
1 Torque on hexagon nut of camshaft sprocket
(SW 30) 240 Nm +/-12.
2 Fillister socket head screw (SW 8) of timing
belt tensioner at 45 Nm +/-4.
3 3 TORX screws on vibration damper with
135 Nm +/-4.
34 Remove locking pin on crankshaft.
