Stihl MS 362 Manual

113MS 362, MS 362 C
: Unscrew the nut (1).
– Remove the washer.
: Remove the heater switch (1)
from inside, check and replace if
necessary.
Installing
: Position the heater switch with
the groove (arrow) facing up.
: Push the heater switch (1)
through the hole in the carburetor
box.
1
0001RA437 TG0001RA438 TG
1
0001RA439 TG
1
– Check operation.
– Reassemble all other parts in the
reverse sequence.
– Tightening torques, b 2.5
13.5 Heating Element in Rear
Handle
The ambient temperature during
removal and installation should not
be less than + 15°C.
– Remove the handle molding,
b 10.2
– Remove the interlock lever,
b 10.2
: Pull the wires out of the guides
(arrows).
: Push back the insulating tubes
(1) in the direction of the wiring
harness and separate the pin and
socket connectors.
0001RA441 TG
1
1
0001RA440 TG
: Check the heating element and
replace if necessary.
If the heating element is in good
condition the ohmmeter will indicate
a value of about 2 Ω in measuring
range "Ω".
If the reading is outside this range,
install a new heating element.
Heating element does not operate
even though resistance
measurement is ok?
– Test the generator and heater
switch, b 13.3
100
50
30
20
10
5
20
10
5
1
2
0001RA442 TG

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
