79MS 362, MS 362 C
10.2 Throttle Trigger/
Interlock Lever
: Push the tabs (1) apart and
through the tank housing.
: Remove the handle molding (1).
The interlock lever (arrow) may pop
out.
: Take the throttle rod (1) out of the
guide (arrow) and disconnect it
from the throttle trigger (2).
1
1
0001RA274 TG
1
0001RA275 TG
2
0001RA276 TG
1
: Ease the interlock lever (1) out of
its mounts (arrows).
Disconnect the torsion spring and
remove the interlock lever.
: Use a drift (2) to drive out the
pin (1).
: Remove the throttle trigger (1)
with torsion spring (2).
1
0001RA277 TG0001RA278 TG
2
1
0001RA279 TG
1
2
Check the interlock lever (1),
throttle trigger (2) and torsion
spring (1) and replace if
necessary
Installing
: Attach the torsion spring (1) to
the trigger (2) – note the installed
position (arrow).
: Place the throttle trigger (1) in the
handle and line up the holes in
the trigger and handle.
0001RA280 TG
3
2
1
0001RA281 TG
2
1
0001RA282 TG
1
