Stihl MS 362 Manual

84 MS 362, MS 362 C
: Position the choke rod (1) in the
guide (arrow).
– Rotate the switch shaft (2) until
the choke rod (1) snaps into
position.
– Check operation.
– Rotate the switch shaft. If
necessary, push home the choke
rod until it is properly seated.
10.3.4 Throttle Rod
– Disconnect the throttle rod from
the trigger, b 10.2
– Remove the filter base, b 12.3
: Pry the throttle rod (1) out of the
carburetor carrier (2).
0001RA302 TG
2
1
0001RA303 TG
1
2
: Pull the throttle rod in the
direction of the handle until its
bent end (1) is in front of the
opening (arrow).
: Rotate the throttle rod (1) about
90° counterclockwise. Pass the
throttle rod (1) through the
opening (arrow) in the direction of
the tank housing and remove it.
– Check the throttle rod and
replace if necessary
Installing
: Line up the throttle rod (1) (see
illustration).
0001RA304 TG
1
0001RA305 TG
1
0001RA307 TG
1
: Push the throttle rod (1) between
the tank housing and air guide
shroud and rotate it about 90° at
the same time.
: Pass the throttle rod (1) through
the opening (arrow).
: Rotate the bent end (1) clockwise
and push it under the throttle
trigger.
: Push the throttle rod (1) into the
guide (2) in the carburetor carrier
until it snaps into position.
– Check operation.
– The throttle lever on the
carburetor must move upwards
when then throttle trigger is
pulled.
– Reassemble in the reverse
sequence.
0001RA309 TG
1
0001RA310 TG
1
2

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
