Stihl MS 362 Manual

85MS 362, MS 362 C
11. Chain Lubrication
11.1 Pickup Body
Impurities gradually clog the fine
pores of the filter with minute
particles of dirt. This prevents the oil
pump from supplying sufficient oil.
In the event of problems with the oil
supply system, first check the oil
tank and the pickup body. Clean the
oil tank if necessary, b 1
– Troubleshooting, b 3.3
– Open the oil tank cap and drain
the oil tank.
– Collect chain oil in a clean
container, b 1
: Use hook (2) 5910 893 8800 to
remove the pickup body (1) from
the oil tank.
Do not overstretch the suction hose.
– Pull off the pickup body (1), check
it and replace if necessary.
– Reassemble in the reverse
sequence.
219RA457 TG
1
2
11.2 Oil Suction Hose
– Remove the clutch, b 4
– Remove the brake band, b 5.2
– Open the oil tank cap and drain
the oil tank b 1.
– Remove the oil pump, b 11.3
: Remove the oil suction hose (1).
– Check the oil suction hose and
pickup body and replace if
necessary.
– Fit the pickup body, b 11.1
Installing
: Push the oil suction hose (1),
pickup body first, through the
housing bore (arrow).
0001RA311 TG
1
0001RA312 TG
1
: Line up the oil suction hose (1)
– the tab (arrow) must be in the
guide.
– Push home the oil suction hose
(1) until its groove is properly
seated in the crankcase.
– Check position of the pickup body
and, if necessary, use the hook
5910 893 8800 to re-position it.
– Install the oil pump, b 11.3
– Reassemble all other parts in the
reverse sequence.
– Tightening torques, b 2.5
0001RA313 TG
1

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
