31MS 362, MS 362 C
: Fit the O-ring in the spur gear
recess (arrow).
– Clean all disassembled parts with
a little standard commercial
solvent-based degreasant
containing no chlorinated or
halogenated hydrocarbons.
– Lubricate the threads, gears and
O-ring with STIHL multipurpose
grease, b 15
– Reassemble in the reverse
sequence.
5.7.1 Quick Chain
Tensioner
The quick chain tensioner is
installed in the sprocket cover.
: Carefully pry the wing nut (1) out
of the sprocket cover (arrow).
– Check the wing nut (1) and
replace if necessary
165RA458 TG
1
165RA469 TG
– Swing the wing nut (1) upright.
: Push the wing nut (1), thin side
first (see arrow), into the opening
and press it down until it snaps
into position.
: Take out the screw (arrow).
: Remove the cover plate (1) and
adjusting wheel (2).
When installing the adjusting wheel,
make sure its teeth face the cover
plate.
– Reassemble in the reverse
sequence.
1
165RA007 TG
1
2
0001RA001 TG
5.8 Bar Mounting Studs
– Remove the side plate, b 5.2
: Push stud puller 5910 893 0506
(1) over the collar studs (2) as far
as it will go and unscrew the
studs (2) counterclockwise.
: Before installing, coat the threads
(1) of the collar studs with Loctite,
b 15
– Fit the collar studs and tighten
them down firmly.
– Tightening torques, b 2.5
– Reassemble all other parts in the
reverse sequence.
0001RA070 TG
1
22
0001RA071 TG
11

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
