99MS 362, MS 362 C
: Hold lever (1) and lever (2)
together against the stop (arrow).
: Tighten down the screw (3) firmly.
Check operation.
Reassemble all other parts in the
reverse sequence.
0001RA380 TG
2
1
3
0001RA381 TG
12.6.6 Adjusting Screws
Grommet has been removed for the
sake of clarity.
There are three adjusting screws on
the carburetor:
H = high speed screw (1)
L = low speed screw (2)
LA = idle speed screw (3)
If the carburetor cannot be adjusted
properly, the problem may be the
adjusting screws.
The high speed screw H has a
limiter cap, which has to be
removed before the screw is
removed.
Always install a new limiter cap.
Remove the carburetor, b 12.5
See also carburetor
troubleshooting, b 3.6
: Pull off the grommet (1).
0001RA382 TG
1
2
3
0001RA383 TG
1
Low speed screw
: Take out the low speed screw (1).
Inspect the sealing ring (1),
washer (2) and spring and
replace if necessary.
: Inspect the tip (arrow) for
damage or wear and replace the
low speed screw (L) if necessary.
Screw down the low speed screw
(L) as far as stop.
Continue with the high speed
screw.
1
0001RA384 TG
0001RA467 TG
1 2
3
