100 MS 362, MS 362 C
High speed screw
The high speed screw H has a
limiter cap, which has to be
removed before the screw is
removed.
: Screw the puller (1) 5910 890
4500 counterclockwise into the
limiter cap – left-hand thread.
: Rotate the limiter cap until the lug
(2) is in line with the slot (1).
: Pull out the limiter cap (1).
1
0001RA386 TG
1
2
0001RA387 TG0001RA388 TG
1
– Take out the high speed
screw (H).
Always install a new limiter cap.
: Inspect the tip (arrow) for
damage or wear and replace the
high speed screw (H) if
necessary.
– Screw down the high speed
screw (H) as far as stop.
– Continue with pre-installing
limiter cap.
Pre-installing limiter cap
: Push the new limiter cap (1) on to
the high speed screw (H) as far
as the detent (arrow) – do not
push fully home.
The basic setting is performed
through the pre-installed limiter cap
with screwdriver 5910 890 2304.
165RA371 TG
165RA372 TG
1
– Reassemble in the reverse
sequence.
– Carry out the basic setting,
b 12.7.1
12.7 Adjusting the Carburetor
12.7.1 Basic Setting
The basic setting is necessary only
if the high speed screw (H) or low
speed screw (L) has to be replaced
or after cleaning and adjusting the
carburetor from scratch.
It is necessary to carry out the basic
setting after removing the limiter
cap.
The carburetor, air filter and
grommet are installed, the adjusting
screws fitted and the new limiter cap
pre-installed.
– Check chain tension and adjust if
necessary.
– Inspect the spark arresting
screen (if fitted) and clean or
replace if necessary, b 3.7 or
b 6.1
– Check the air filter and clean or
replace if necessary, b 12.1

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
