82 MS 362, MS 362 C
: Engage lugs (2) at front end of
handle molding (1) in the
recesses (arrow).
– Press the interlock lever down.
– Push down the handle molding
(1) until it snaps into position.
– Check operation.
– Reassemble all other parts in the
reverse sequence.
– Tightening torques, b 2.5
10.3.1 Switch Lever –
QuickStop Super
– Remove the handle molding,
b 10.3
: Use a drift (1) to drive out the pin
(arrow).
0001RA287 TG
2
1
0001RA488 TG
1
– Lift the switch lever (1) slightly.
: Turn the switch lever (1) about
90! and pull it off the brake
cable (2).
– Check the switch lever (1) and
replace it if necessary
Installing
: Connect the brake cable (1) to
the bore (arrow) in the switch
lever.
– Turn the switch lever so that it
faces up.
219RA448 TG
1
2
1
0001RA457 TG
: Use a drift (2) to center the switch
lever (1).
: Drive home the pin (3) until it is
recessed by same amount at
both sides.
– Reassemble in the reverse
sequence.
– Tightening torques, b 2.5
– Check operation of switch lever
by operating the interlock lever.
10.3.2 Interlock Lever –
QuickStop Super
– Remove the handle molding,
b 10.3
: Use a drift (1) to drive out the pin
(arrow).
– Take out the interlock lever.
1
3
0001RA458 TG
2
0001RA489 TG
1

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
