Stihl MS 362 Manual

37MS 362, MS 362 C
Installing
: Fit the installing sleeve (1) 1122
893 4600.
– Slip the oil seal, open side facing
the crankcase, over the installing
sleeve.
– Remove the installing sleeve (1).
: Use press sleeve (1) 1118 893
2401 to install the oil seal (2).
0001RA096 TG
1
0001RA097 TG
2
1
: Fit the E-clip (1).
– Wait about one minute, then
rotate the crankshaft several
times.
– Reassemble all other parts in the
reverse sequence.
– Tightening torques, b 2.5
6.4 Shroud
– Set the Master Control lever
to "
0".
– Push the front hand guard
forwards to engage the chain
brake.
: Open the quick-action locks
(arrows).
– Use the combination wrench
to turn them a 1/4 turn
counterclockwise.
– Remove the shroud (1).
0001RA098 TG
1
0001RA099 TG
1
– Reassemble in the reverse
sequence.
6.5 Cylinder
Before removing the piston, decide
whether or not the crankshaft has to
be removed as well.
Cylinder installed
To remove the flywheel and clutch,
the crankshaft has to be blocked by
inserting the locking strip in the
spark plug hole.
Cylinder removed
To remove the flywheel and clutch,
the crankshaft has to be blocked by
resting the piston on the wooden
assembly block.
– Remove the shroud, b 6.4
– Pull off the boot and unscrew the
spark plug, b 4
– Remove the fan housing,
b 8.2
– Remove the filter base, b 12.3
– Remove the carburetor, b 12.5
– Remove the manifold, b 12.9
– Remove the muffler, b 6.1
– Remove the decompression
valve, b 6.9
– Remove AV spring from
handlebar, b 9.4

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
