47MS 362, MS 362 C
: Attach the snap ring (1) to the
magnet (2) so that the snap ring
gap is on the flat side of the tool's
shank (arrow).
: Push the large slotted diameter of
the sleeve over the magnet and
snap ring.
The inner pin (1) must point towards
the flat face of the
tool's shank (2).
: Press the installing tool
downwards into the sleeve until
the magnet butts against the end
of the guide slot.
Use a suitable base.
165RA153 TG
1
2
12
0001RA482 TG0001RA483 TG
: Remove the sleeve and slip it
onto the other end of the shank –
the inner pin must point towards
the flat face.
: Apply the installing tool
5910 890 2212 with the sleeve’s
taper against the piston boss,
hold the piston steady, center the
tool shank exactly and press
home until the snap ring slips into
the groove.
Make sure the tool shank is held
square on the piston pin axis.
216RA178 TG
0001RA484 TG
Fit the snap ring (1) so that its gap
(arrow) points either up or down.
– Inspect the piston rings and
replace if necessary, b 6.8
– Install the cylinder, b 6.5
– Reassemble all other parts in the
reverse sequence.
– Tightening torques, b 2.5
0001RA329 TG
1
0001RA330 TG

Stihl MS 362 Specifications

General

Displacement	59.0 cm³
Powerhead Weight	5.6 kg
Chain pitch	3/8"
Vibration level (left/right)	3.5/3.5 m/s²
Weight	5.6 kg
Guide Bar Length	40-50 cm (16-20 in)
Oil Capacity	325 cc
Weight (without cutting equipment)	5.6 kg
Oil tank volume	325 cc
