7MS 362, MS 362 C
Fastener Thread size For component Torque
Nm
Remarks
Screw M 4x12 Oil pump/crankcase 3.0 4)
Screw M 5x25 Muffler/crankcase 10.0
Screw M 5x16 Muffler / cylinder 10.0 4)
Nut M 12x0.75 Switch/handle housing (VW) 6.0
Screw M 4x10 Guard/tank housing 1.5
Nut M 8x1 Flywheel/crankshaft 33.0 5)
Screw M 4x8 Side plate/crankcase 3.0
Nut M 5 Carburetor/collar stud 3.5
Screw M 4x12 Preseparator/crankcase 3.0 1), 4)
Screw M 5x20 Elbow/handlebar (R) 7.0 4)
Screw D 4x15 Cover plate/fan housing 3.0
M 14x1.25 Spark plug 25.0
Screw M 5x20 Ignition module/crankcase 8.0 4)
Screw M 5x25 Cylinder/crankcase, 1st stage 4.0 4)
Screw M 5x25 Cylinder/crankcase, 2nd stage 10.0 4)
Screw P 6x25 Crankcase/bearing plug (R) 5.0
Remarks:
1) Loctite 242 or 243, medium strength
2) Loctite 649, high strength
3) Loctite 270, high strength
4) Screws with binding head
5) Degrease crankshaft/flywheel and mount oil-free
VW) Carburetor and handle heating system
R) Wrap-around handle
Q) QuickStop Super
Use the following procedure when refitting a DG or P screw in an existing thread:
Place the screw in the hole and rotate it counterclockwise until it drops down slightly.
Tighten the screw clockwise to the specified torque.
This procedure ensures that the screw engages properly in the existing thread and does not form a new thread
and weaken the assembly.
Coat micro-encapsulated screws with medium strength Loctite 242 or 243 before reinstalling.
Power screwdriver setting for polymer: DG and P screws max. 500 rpm
Do not use an impact wrench for releasing or tightening screws.
Do not mix up screws with and without binding heads.
