Stulz EC Tower ECD 91 - Page 192

192 EN/01.2019/G22 © STULZ GmbH – all rights reserved
ec tower technical manual
© Danfoss | DCS (az) |2017.06
IC.PD.200.H7.02 | 4
Data sheet | Solenoid valves, type EV250B, dezincification resistant brass
Dimensions and weight: DZR brass, NC and NO
Type
Weight gross,
valve body without
coil
[kg]
L
[mm]
B
[mm]
B
1
[mm] / Coil type
H
[mm]
H
1
[mm]BB/BE BG/BN
EV250B 12 0.6 58 52.3 46 68 91 12.5
Mounting angle
Dimensions
© Danfoss | DCS (az) |2017.06
IC.PD.200.H7.02 | 5
Data sheet | Solenoid valves, type EV250B, dezincification resistant brass
Coil EV250B
Coil
Type
Power consumption Enclosure Features
BE, clip on
10 W AC
18 W DC
IP67 With terminal box
