8-10 SPARCclassic/SPARCclassic X/SPARCstation LX Service Manual • November 1993
FIGURE 8-4 Extracting the Main Logic Board
FIGURE 8-5 Raising the Speaker/LED Assembly
System I/O board
Main logic board
Speaker/power
LED assembly
Main logic board extractor
Squeeze the two levers
at the base of the assembly,
and slide the assembly up.
