4. Slide the LED into the LED cavity on the chassis. Push it into the cavity until it
comes in contact with the locating stop.
See Figure 15–8.
Figure 15–8 Connecting the LED Connector to the LED
5. Lay out the DC power harness in the chassis.
See Figure 15–9.
