SV 200A User Manual
36
SplitTime[5]
Logger files splitting time:
-1 - off.
0:1439 - Time in minutes.
Valid only if SplitMode is equal 1440.
37
SplitTime[6]
Logger files splitting time:
-1 - off.
0:1439 - Time in minutes.
Valid only if SplitMode is equal 1440.
38
GpsLastSyncTime
The time [s] between clock synchronization from GPS module
and the start of measurement.
0xffff - no synchronization
39
StatisticsCycles
Number of IntTimes statistics are calculated for 1:32767
40..41
MeasureStartTimeMs
measurement start time in milliseconds
42
NofDirDistXY
number of elements for directivity distribution vector for X-Y axis
43
NofDirDistZ
number of elements for directivity distribution vector for Z axis
44..47
reserved
…
MEASUREMENT TRIGGER parameters
Word
number
Name
Comment
0
0xnn2B
[2B, nn=block’s length]
1
TriggerMode
trigger mode:
0 - OFF,
2 - measurement on trigger SLOPE+
3 - measurement on trigger SLOPE–
4 - measurement on trigger LEVEL+
5 - measurement on trigger LEVEL–
6 - measurement on trigger GRAD+
7 - measurement on trigger EXT I/O
2
TriggerSource
source of the triggering signal:
0 - RMS(1) the RMS result from the first profile
3
TriggerLevel
level of triggering:
25 ÷ 130 dB (*10)
4
TriggerGrad
gradient of triggering:
1 dB/ms ÷ 100 dB/ms (*10)
5
TriggerPre
reserved
6
TriggerPost
reserved
7
TriggerSampling
reserved
8
TriggerRecTime
reserved
9
TriggerStep
reserved
10
TriggerFilter
reserved
11
TriggerBitsPerSample
reserved
12
Range
reserved
…
