Svantek SV 200A User Manual

135
SV 200A User Manual
Results of the statistical analysis
Word
number
Name
Comment
0
0x010B
[0B, prof_mask#1]
1
SubblockLength
2 * number of classes in the first profile + 2
2..3
Histogram[1][1]
the first counter in the first profile
4..5
Histogram[1][2]
the second counter in the first profile
.....
.....
.....
0
0x020B
[0B, prof_mask#2]
1
SubblockLength
2 * number of classes in the second profile + 2
2..3
Histogram[2][1]
the first counter in the second profile
4..5
Histogram[2][2]
the second counter in the second profile
.....
.....
.....
0
0x040B
[0B, prof_mask#3]
1
SubblockLength
2 * number of classes in the third profile + 2
2..3
Histogram[3][1]
the first counter in the third profile
4..5
Histogram[3][2]
the second counter in the third profile
.....
.....
.....
1/1 OCTAVE analysis results
Word
number
Name
Comment
0
0xnn0E, 0xnn26,
0xnn27
[block_id, nn=block_length]
0xnnOE - averaged spectrum results, 0xnn26 - min. spectrum
results, 0xnn27 - max. spectrum results
1
0x0101
[used_profile, profile’s mask]
2
LowestFreq
the lowest 1/1 OCTAVE frequency (*100 Hz): 3150 (AUDIO
BAND)
3
NOct
number of 1/1 OCTAVE values: 10 (AUDIO BAND)
4
NOctTot
number of TOTAL values: 3
5÷20
Octave[i]
1/1 octave[i] value (*10 dB); i=1÷NOct+NoctTot (1÷13)
…
…
…
1/3 OCTAVE analysis results
Word
number
Name
Comment
0
0xnn10, 0xnn28,
0xnn29
[block_id, nn=block_length]
0xnn10 - averaged spectrum results, 0xnn28 - min. spectrum
results, 0xnn29 - max. spectrum results
1
0x0101
[used_profile, profile’s mask]
2
LowestFreq
the lowest 1/3 OCTAVE frequency (*100 Hz): 2000 (AUDIO
BAND)
3
NTer
number of 1/3 OCTAVE values: 31 (AUDIO BAND)
4
NTerTot
number of TOTAL values: 3
5÷50
Tercje[i]
1/3 octave[i] value (*10 dB); i=1÷NTer+NTerTot (1÷34)
…
…
…
