Svantek SV 200A User Manual

18
SV 200A User Manual
6. Hold the outer cone with one hand,
use the other hand to screw on the
microphone protective sleeve
rotating it clockwise.
7. Align moving ring with the slot of the
microphone protective sleeve so that
the cable is not bent in any direction.
Gently place the actuator located at
the end of the cable in the dedicated
socket. Put the actuator's cable into
the slot of the sleeve.
If the actuator's cable is too long,
decrease the length pushing its
lower end inside the casing.
Note: It is important to keep the microphone protective sleeve still, to protect actuator’s cable from
damage.
hold firmly with one hand
screw the sleeve on
insert into the socket
place the actuator cable
in the slot of the sleeve
align with the slot of the
sleeve
